| Model |
H-740 |
H-745 |
|
Processor |
Intel Celeron 2.0GHz / Pentium 4 2.4GHz (socket 478) |
|
System Memory |
256MB standard, maximum 1GB (1 x 184-pin DDR) |
|
Power Supply |
250W External Power Supply |
|
Storage Device |
1 x 3.5" SATA HDD, 1 x CF Card (optional) |
|
Construction |
Aluminum Die-casting |
|
Housing Color |
Black / Silver |
| Touch LCD Display |
|
Size / Resolution |
12" TFT LCD / 800 x 600 |
15" TFT LCD / 1024 x 768 |
|
Brightness |
400 cd/㎡ |
250 / 350 cd/㎡ |
|
Touch Screen |
5 / 4 wire Resistive |
| I/O Ports |
|
Serial Port |
4 x External: COM1 & COM2 (D-Sub) |
|
USB Port |
4 x External |
|
Printer Port |
1 x Bi-directional Parallel port |
|
Cash Drawer Port |
1 x 12V RJ11 (single/dual) |
|
PS/2 |
1 x Keyboard, 1 x Mouse |
|
LAN Port |
1 x RJ45 10/100 |
|
Video Port |
1 x VGA |
|
Audio Port |
1 x Line-out |
|
DC Output |
1 x 12V for 2nd display |
| OS Supported |
|
Windows |
2000, XP Pro, XP Embedded, WEPOS, POS Ready 2009 |
|
Linux |
Fedora 8, Open SuSE 11 |
| Physical Dimensions |
|
Dimensions (W x H x D) |
320 x 304 x 265 mm |
370 x 350 x 265 mm |
| Environment |
|
EMI / Safety |
CE, FCC, CCC |
|
Operating Temperature |
0°C~35°C(32°F~ 95°F) |
|
Storage Temperature |
-10°C~ 40°C(14°F~ 104°F) |
|
Relative Humidity |
10% ~ 90% (non-condensing) |
| Optional Peripherals |
|
Magnetic Stripe Card Reader |
MCR single/dual/triple Track |
|
2-in1 / 3-in1 Module |
MCR+i-Button/MCR+RFID/MCR+Fingerprint/MCR+Smartcard+i-Button |
|
2nd Display |
12.1" TFT LCD with touch/non-touch |
|
Cusotmer Display |
Integrated VFD/LCD Customer Pole Dispaly |
